Specifications

CK6432x500/750mm

Machining capacity

Max.swing over bed

360mm

Max.swing over cross slide

155mm

Max.length of workpiece

750/1000/1500mm

Width of bed

260mm

Spindle

Spindle speed range

150-2500rpm

spindle bore

60mm

spindle nose

A2-6

Taper of spindle bore

MT6

Chuck diameter

200mm

Slide stroke

X-axis travel

350mm

Z-axis travel

500/750mm

X-axis rapid moving

6m/min

z-axis rapid moving

8m/min

Turret

Tool station number

4 or 6 or 8 or Tool array

Max.section of tool

20x20mm, 16x16mm

Tailstock sleeve

External diameter

50mm

Max.travel

110mm

Taper of bore

MT4

Motor

Main motor power

4KW

Coolant pump power

120W

Machine dimension

Overall dimension

1800/2060/1200x1200x1600mm

Packing size

1920/2180/2324x1460x2000mm

Net weight

1275/1450kg

Gross weight

1450/1650kg
