| Specifications | CK6166 |
| Machining capacity | |
| Max.swing over bed | 660mm |
| Max.swing over cross slide | 280mm |
| Max.length of workpiece | 750/1000/1500mm |
| Width of bed | 400mm |
| Spindle | |
| Spindle speed range | 150-1600rpm |
| 30-150/100-500/150-1600rpm | |
| spindle bore | 82mm |
| spinle nose | A2-8 |
| Taper of spindle bore | 90mm 1:20 |
| Chuck diameter | 250mm |
| Slide stroke | |
| X-axis travel | 350mm |
| Z-axis travel | 750/1000/1500mm |
| X-axis rapid moving | 6m/min |
| z-axis rapid moving | 8m/min |
| Turret | |
| Tool station number | 4 or 6 or 8 |
| Max.section of tool | 25x25mm |
| Tailstock sleeve | |
| External diameter | 75mm |
| Max.travel | 150mm |
| Taper of bore | MT5 |
| Motor | |
| Main motor power | 7.5KW/11KW |
| Coolant pump power | 120W |
| Machine dimension | |
| Overall dimension | 2420/2860/3320*1800*2060mm |
| Net weight | 2850/3200/3450kg |
Features:
Model CJK mechanical gear shifts as optional
Adaptable to various control system such as GKS, KND, SIEMENS, FANUC
Different appearance shapes such as square , circular arc and so on.
Steel guide rail as optional
Steady cast iron feet
