| Features | |||
| * 超音频淬火床身 | *Induction harden bedway | ||
| * 主轴速度显示 | *Spindle speed readout | ||
| * 无级变速 | *Variable speed | ||
| * 直流电机 | *DC motor | ||
| 技术参数 Specification | |||
| 型号 | MODEL NO. | TL0714 | |
| 两顶尖的距离 | Distance between centers | 200/300/350mm | |
| 最大回转直径 | Swing over bed | 180mm | |
| 主轴内孔锥度 | Sindle taper | MT3 | |
| 三爪卡盘外径 | Chuck diameter | 80mm | |
| 主轴通孔直径 | Spindle bore | 20mm | |
| 刀架行程 | Tool slide travel | 35mm | |
| 尾架套筒锥度 | Taper of tailstock quill | MT2 | |
| 公制螺纹范围 | Range of metric threads | 0.5-2.5mm | |
| 英制螺纹范围 | Range of inch threads | 12-52TPL | |
| 中拖板行程 | Cross slide travel | 65mm | |
| 主轴精度 | Spindle accuracy | 0.01mm | |
| 主轴转速 | Spindle speed | 50-2500RPM | |
| 电压/频率 | Vol./Freq | 230V/50Hz or 120V/60Hz | |
| 电机功率 | Motor | 400W | |
| 净重 | Net weight | 35/38/40KG | |
| 毛重 | Gross weight | 38/42/45KG | |
| 包装尺寸 | Packing size | 660/760/810*305*370mm | |
| 标准配件Standard Accessories | 特殊配件 Optional Accessories | ||
| 三爪卡盘 3-jaw chuck ∮80 | 四爪卡盘 4-jaw chuck | ||
| 挂轮 Change gears | 跟刀架 Follow rest | ||
| 顶尖 Centers MT2 | 中心架 Steady rest | ||
| 油枪 Oil gun | 花盘 Face plate 125mm | ||
| 各种板手 Set of wrench | 床脚 Stand | ||
